Status Quad 4 StQ 144 4 elements 2 m
4-element cubical quad antenna for 144 MHz, 1.82 m boom, aluminium and fibreglass construction
The Status Quad 4 StQ 144 is a 4-element cubical quad antenna for 144 MHz, built in Italy by Status Quad with a 1.82 m boom.
Product description
Status Quad 6 m and VHF antennas are made with the same care as the HF models, focusing on mechanical reliability and ease of assembly.
The boom-to-mast plate is entirely aluminium, CNC cut and drilled, with the boom seat machined into the plate to prevent any movement. Aluminium U-bolts clamp masts from 40 to 65 mm.
The boom is 50 × 50 mm square aluminium tube, 2 mm thick. The elements are 10 mm fibreglass rods and the conductor is held by spreaders designed by Status Quad. The loops are 2.57 mm aluminium braid.
Key features
Boom locked with no play.
Square aluminium tube.
2.57 mm aluminium.
Technical specifications
| Type | 4-element quad |
| Band | 144 MHz |
| Boom length | 1.82 m |
| Boom | 50 × 50 mm square aluminium, 2 mm thick |
| Elements | Ø 10 mm fibreglass rod |
| Loop | Ø 2.57 mm aluminium braid |
| Plate | CNC-machined aluminium |
| Mast | Ø 40–65 mm |
