Status Quad 2 StQ 5 2 elements 5 bands
5-band cubical quad antenna for 20, 17, 15, 12 and 10 m, 2 elements per band, 2.55 m boom
The Status Quad 2 StQ 5 is a 5-band HF cubical quad antenna for 20, 17, 15, 12 and 10 metres, built in Italy by Status Quad.
Product description
It has 2 elements on each of the 20, 17, 15, 12 and 10 metre bands, with a 2.55 m boom.
The optional 3 StQ 50 kit for 50 MHz can be mounted on the same boom: this gives a full-size six-band quad on a single boom.
As an option, the element guying kit can be added, even after installation: 25 mm fibreglass boom extensions, 3 mm Mastrant guys linking the elements to each other and to the extensions, and a Mastrant loop on each element. The kit prevents the fibreglass spreaders from moving in strong wind or with snow on the wire: the structure stays just flexible enough to absorb wind thrust without ever exceeding the critical level of mechanical stress.
Key features
20, 17, 15, 12 and 10 m.
3 StQ 50 kit for 50 MHz on the same boom.
Optional, against wind and snow.
Technical specifications
| Type | 5-band HF quad |
| Bands | 20 / 17 / 15 / 12 / 10 m |
| Elements per band | 2 on all bands |
| Boom length | 2.55 m |
